Custom led aluminium pcb board led light pcba design
The customized aluminum LED PCBA light board, is specifically designed for 5050 RGB SMD LEDs. It supports both 12V and 24V input voltages and has a power rating of 18W. The PCB features an aluminum base that p
Custom led aluminium pcb led light pcba design
rovides efficient heat dissipation, ensuring optimal performance and longevity of the LEDs.
| Product Name | Custom led aluminium pcb |
| Type | PCB |
| Material | FR4, CEM1, CEM3, High Frequency Board, |
| Layer | 1,2,4,6 Layers |
| Shape | Rectangular, Round, Slots, Cutouts, Complex, Irregular |
| Cutting | Shear, V-score, Tab-routed |
| Copper Thickness | 0.5-4oz, regular 1oz |
| Solder Mask | Green, Red, Blue, Yellow, etc. |
| Silk Screen | White, Black, etc. |
| Silk Screen Min Line Width | 0.006 or 0.15mm |
| Min Trace/Gap | 0.1mm or 4mils |
| Min Drill Hole Diameter | 0.01 ,0.25mm or 10mils |
| Surface Finish | HASL, ENIG, OSP, etc. |
